Bambu Lab 4-in-1 PTFE Adapter
From
$4.99 USD
Unit price
/
Unavailable
Bambu Lab 4-in-1 PTFE Adapter
Overview
The Bambu 4-in-1 PTFE Adapter is an adapter used to connect the PTFE tube. Compared to the original PTFE tube connector, the 4-in-1 adapter can connect 4 feeder modules to the printer at the same time. (up to 7 different filaments: 1 AMS and other 3 filaments)
It can help users to connect the printer to AMS along with other filaments which are not compatible with AMS such as TPU 95A, Bambu PET-CF and other brands' carbon-fiber/glass-fiber contained filaments.
Installation
Learn more about the replacement of Bambu 4-in-1 PTFE Adapter on Bambu Lab Wiki.
Compatibility
X1 Series/P1 Series/H2 Series
In the Box
For X1 Series/P1 Series/H2D/H2S
- Bambu 4-in-1 PTFE Adapter *1
For H2C
- 4-In-1 PTFE Adapter II *1
- 4-in-1 PTFE adapter filament II cleaning pad *5
Instructions for use
The Bambu 4-in-1 PTFE Adapter is designed with a clear direction of use, as shown in the figure below. 1. When using AMS:- Connect the PTFE tube from the tool head to the OUT end of the Bambu 4-in-1 PTFE Adapter.
- Connect the PTFE tube from the buffer output to one of its IN ends. - Directly insert a maximum of three filament wires into each hole of the Bambu 4-in-1 PTFE Adapter IN end.
- Connect the PTFE tube from the tool head to the OUT end of the Bambu 4-in-1 PTFE Adapter.
- Directly insert a maximum of four filament wires into each hole of the Bambu 4-in-1 PTFE Adapter IN end.
It is important to note that reversing connections may cause filament blockage. Therefore, it is essential to ensure that the installation direction is correct.
Part details
Fits: A1 Series, A1 mini, H2 Series, P1 Series, X1 Series
| Option | SKU / part code | Additional Part Code(s) |
|---|---|---|
| Legacy (White) | FAZ013-N | FAZ013 |
| Updated (Gray) | SA014 |
Condition: New, genuine Bambu Lab parts
